Specifications
Measurement Frequencies (kHz)
i50 : 1, 5, 50, 100, 250, 500 i55 : 1, 5, 50, 250, 500, 1000
Display
10.4 inch (768 x 1024), Full Touch Screen
Power Specifications
Input - AC 100~240V, 50~60Hz, 1.5A Output – DC 12V, 5A
Dimensions
472mm(W) x 888mm(D) x 1167mm (H)
Input Interface
Full Touch
Weight
Approx 24 kg
External Interfaces
RS232 (9-pin serial cable) 1EA USB Host 4EA Mini-USB 1EA LAN 1EA
Measurement Time
Approx 60 secs
